MAXX ASG Flybarless System with Rescue Function

Maxxtronik
|
MXK-1001
You will earn 210.56 points for buying this product
Price Match Guarantee
$210.56 $0.00( / )
MAXX ASG FLYBARLESS SYSTEM WITH RESCUE FUNCTION PERFORMANCE-INNOVATION-AFFORDABILITY Manual: https://bit.ly/3k4vp4T Introductions: With the aim to build the best flybarless system at affordable price, MAXX flybarless unit is designed with most advanced MCU gyro and 6-axis sensors to deliver best performance and full features at the price everyone can afford. Designed by a team...

MAXX ASG FLYBARLESS SYSTEM WITH RESCUE FUNCTION

PERFORMANCE-INNOVATION-AFFORDABILITY

Manual: https://bit.ly/3k4vp4T

Introductions:

With the aim to build the best flybarless system at affordable price, MAXX flybarless unit is

designed with most advanced MCU gyro and 6-axis sensors to deliver best performance and full

features at the price everyone can afford. Designed by a team of pilots with years of experience

and tested by best pilots in the world, this MAXX flybarless system not only brings affordable

flybarless units but also the most innovative product to the market.

Very low sensor offset drift due to temperature and long flight time. That will give a really

well-balanced for tail and cyclic.

Cyclic and throttle Servo 760us type supported.

SRXL2 and Telemetry supported.

Can be upgraded to an “Automatic Glow plug system” for nitro helicopters by equipping

additional MXK-1004 device.

Vibration Resistant :

MAXX Flybarless System uses newest technology sensors with very high sample rate, high

resolution and low thermal offset drift. The flybarless unit is extremely vibration resistant and

very stable flight for any helicopter size.

The MEMS sensor inside the Maxx FBL can read 4 to 16 times faster with extremely low noise.

So it is capable of analyzing and eliminating high frequency vibrations.

Also for that reason, the sensor inside the Maxx FBL is capable of upgrading to a GPS autopilot,

it is capable of detecting the smallest moving in the air.

Not only that, it makes your servo always controlled with the least noise signal.

Fast respone from sensor:

It reacts quickly and corrects the smallest movement of your heli to provides smooth and stable

control. So the tail and cyclic direction is very good under all flight conditions, more power tail

hold.

Simplified Setup:

Easy setup with MAXX Software. Customers can use mLink port for connection to MAXX

programs card and MAXX ecosystem in the future.

MAXX flybarless system brings a feeling of good flying with the default setup, reducing the first

setup time. Especially the new tail control algorithm offers good tail control with default setup on

all helicopter kits.

Ability to tunning tail gain by the transmitter (CH5).

Advance Setup:

Ability to customize Cyclic, Tail PID gain according to more flight styles and mechanical

difference of each helicopter. You can separately setup the gain of elevartor and aileron.

Bank manage: The Maxx has 3 Cyclic, Rpm banks memory allows you to set 3 flight modes

accordingly.

Dual Satellite Port and SRXL/SRXL2 support with telemetry:

The MAXX flybarless has Dual Satellite Port providing more reliability for large helicopters and

long range flights, ability to BIND by MAXX software or program card.

Built-in Electric and Nitro Governor:

MAXX active governor can throtle compensation , it calculated according to cyclic, collective,

tail, RPM and other status of Flybarless units. It offers very stability in RPM and more powerful,

more efficiency with no effect to the tail.

The RPM is set exactly the RPM value for each Bank.

Nitro Governor: MAXX flybarless supports Governor for Nitro Helicoper, using magnetic RPM

sensor connect to RPM in pin of unit. Minimum 7 chanels on transmitter is required for Nitro

Governor. The throtle chanel is set up to V-shape for fast respone. RPM is decided by CH7

(AUX2) channels on TX to trigger the Bank, setting and not decided by throttle chanel.

The Maxx supports 760us throttle servo.

Electric Governor: Use RPM wire output of Esc or RPM sensor connect to RPM input pin .

Minimum 6 chanel transmitter is required for electric governor. You can use 760us for throttle

servo.

Event Logging and High sample rate Vibration logging:

The memory of unit stores data of 5 last flights.

Event logging: Time of Radio signal, motor run/stop , BEC voltage drop

Vibration logging : Ability to review the vibration level when flying by graph form on the MAXX

software

AutoTrim Piro:

No more manual adjust for swashplate. With MAXX flybarless, there is no need to spend a lot of

time to balance the swashplate. The software can detect unbalance of swashplate in piro hover

flight and autotrim the swashplate. It can function correctly even in high winds.

Rescue:

Rescue mode is activated when the helicopter tilt angle is over threshold degrees with ground

and have event Gyro gain (CH5) value drops from high to below centre value (1520us). The

helicoper will automatically flip back then automatically increase the height. Within 3 seconds the

rescue mode will exit.

With advance accelerator sensors our MAXX flybarless system has the most accurate calculation

for most accurate rescue. This saves a lot of crashes and a great tool for beginners to learn to

fly.

Example: CH5 on Tx is 35% for flight, so you should be set CH5 on Tx is -35% (or 35% normal

mode, not AVCS) for rescue mode , reaction of the tail will not change.

Drop Radio Signal Indicator:

The LED light on the MAXX unit will blink if detecting more than 50ms radio signal loss. This can

be viewed in table Logger in the MAXX software.

Bec Drop Detector:

Nowadays, servos are very strong and getting stronger, many crashes are due to weak BEC or

bad connection. With MAXX flybarless, there is no more worries about this. Introducing an

innovative feature: BEC Drop Dectector that helps prevent many crashes. MAXX flybarless

keeps reading voltage of BEC continuously before and during flight, if BEC is weak and voltage

drops over 0.5V, the red LED on MAXX flybarless unit will double flashed to inform pilot the

problem. The problems are also logged and viewed in table logger in MAXX software for

reference.

LowBec safety setting: It is only checking at startup. If the BEC is below the voltage threshold

have been set the heli can’t fly, the initialize process is not completed.

Ability to GPS upgrade: Upgradable to 10 axis Fight Controller with GPS flight mode. The unit

is compatible with Maxx GPS addon board (MXK-1003) to add barometer, compass turn Maxx

FBL into auto-hover, Return to Home for sacle heli and soft 3D trainning.

Dimensions:36mm x 28.5mm x 15mm (LxWxH) / 18g
Application:Any helicopter size, Nitro and Electric Compatible
Receiver Support:S-Bus Ready, PPM , DSM2/DSMX

Satellite,SRXL/SRXL2/SPM4649T Serial Receiver, JR X-Bus,

MaxxBus and Ex-Bus receiver

Cyclic Servo Support:Digital 1520us and 760us(only setting by program card)
Tail Servo Support:760uS / 1520uS – Up To 560Hz Frequency
Input Power3.6 – 9V





Manual: https://bit.ly/3k4vp4T

Type:

Flybarless Systems

Vendor:

Maxxtronik

SKU:

MXK-1001

Weight:

1.0 lb


Product Spare Parts


Electronics

Customer Reviews

Based on 6 reviews
100%
(6)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
T
Tony L.
Second Unit: Not so good, but customer service took care of my problem.

I purchased this unit after purchasing one for a 450 heli which is doing really well.
It is installed on an Align 470LM (which I really like)

Problem 1: During setup while in a hover the heli was pulling to the left, after landing and repowering, It hovered well. Thought it was just a fluke.
Flew 3 flights over 8 minutes afterwards with everything good.

Problem 2: On the 4th and 5th flights while in a 5ft. hover using GPS lost power to the motor.
Contacted Maxx and was instructed to install VER. 1.04 firmware. ( Which I done).
Problem 3: After installing firmware, I tried again, This time I done a 8ft. hover for 3 minutes and thought problem solved. WRONG; at
3 minutes the Heli yawed to the left, Lost control of cyclic input function, flew horizontal and crashed.

Maxx has given prompt replies, I will give them that.

The first one is still rock solid and doing well, Only wish I could say the same for the second.

They replaced the unit after several troubleshooting sessions.The replacement works Great, and Both Maxx and Helidirect have earned
my trust and respect. I ordered a third unit and possibly a fourth for my fleet.

Thanks Helidirect and Maxx!

L
Leo
Very good packaging

I haven't opened and do the setup yet. But I have to give good reviews for helidirect 😝. Good little package look sexy and high class flybarless unit.

T
Tony L.
Fantastic !!

Let me first say, I'm not very proficient at flying helis. That being said, I needed a very good FC and have tried several. This one is the best I have had as it is rock solid.

I'm using a Turnigy (Flysky) I10 radio. I placed it on a 450 DFC helicopter. Setting up is a little tricky as the instructions are catered on the Spektrum Radios. But the unit does program well once you
learn how to get the various aspects correct. I used PPM output. The heli type must be Straight Do Not use CCPM servo mixing function on your radio,as the FC will mix the swashplate.

I also purchased the GPS unit for it.

Digital servos are a must as this unit will not work with analog servos.

Flight patterns are rock solid. It is hard to tell during takeoff and hover if you are in manual or GPS. It is that solid. The GPS will hold the altitude and limit the responses.

Overall I'm very pleased with the unit and would highly recommend it !

Judge.me YouTube video placeholder
C
Customer

Gratis product.

J
JHerison
Maxx Flybarless

First impressions are great, easy setup and nice tough aluminum case. Maiden flight was solid and predictable with default settings.

q
qui n.

Very good
