SAB Goblin RAW 420 - With SAB Motor, Main & Tail Blades

|
SG421
You will earn 589 points for buying this product
Price Match Guarantee
$471.20 $589.00( / )
Manual Download : HERE One of the most revolutionary helicopters of today. The Raw 420 has an incredibly large, direct drive motor offering superb performance for 3D pilots and incredible efficiency for sport flyers and beginners alike! This little heli is designed to run on a 6s pack ranging from...

Manual Download : HERE

One of the most revolutionary helicopters of today. The Raw 420 has an incredibly large, direct drive motor offering superb performance for 3D pilots and incredible efficiency for sport flyers and beginners alike!

This little heli is designed to run on a 6s pack ranging from 2200 to 2700 mAh and comes with motor and blades. You simply need to get servos (micro cyclic & mini tail), an ESC and a flight controller! We recommend either the HobbyWing 60 or 80 A controllers or the Scorpion 06_80A. All of these are excellent choices, if you are planing on doing mild 3D or sport flying, the 60A is the best choice, for harder 3D, then the 80A ESCs are preferred.

The kit ships with one battery tray, make sure to get more if you plan on having more than one battery ready to go.

Raw 420 Main Features:

  • Direct Drive Motor (Competition motor included)
  • New S Line blades (420mm and 70mm included)
  • Quick release battery tray with built-in connectors
  • 10mm one way bearing integrated into the motor
  • Zytel HTN resin blade grip arms (sacrificial)
  • The canopy does not need to be removed to replace batteries
  • Neon yellow color for best visibility (available initially in yellow only)
  • Carbon fiber molded boom as an option also available

Raw 420 Specifications:

  • Airframe weight: 1000 grams (with motor and blades)
  • Main rotor diameter 935mm (with 420mm blades)
  • Main blade length 380 to 420mm
  • Tail rotor diameter 190mm (with 70mm tail blades)
  • Tail blade length 60 to 70mm
  • Micro size cyclic servos (23mm)
  • Mini size tail servo (35mm)
  • Maximum battery size 40x54x135mm
  • Recommended battery 6s 2200/2700 mAh
  • Recommended battery weight 350-420 grams
  • Recommended ESC 60-80 amp
  • Tail rotor ratio 4:1
  • 8mm main shaft
  • 5mm tail shaft


Type:

Helicopter Kit

Vendor:

SAB Heli Division

SKU:

SG421

Weight:

12.0 lb


Product Spare Parts

Customer Reviews

Based on 41 reviews
95%
(39)
5%
(2)
0%
(0)
0%
(0)
0%
(0)
M
Matt
Great Helicopter

SAB has done a great job with the design of this aircraft. The components fit together very well and the well thought out manual makes assembly a breeze. It flies very well and is an extremely capable helicopter. However, I have a few gripes. The proprietary battery connector doesn't come with a charging cable. So basically you need to buy the XT60 connector support to allow you to use a standard connector. Also, the motor is very large and sticks far outside of the airframe. A motor guard should come with the kit instead of being an aftermarket part. These are quite minor in the grand scheme of things. If you are familiar with SAB and are willing to live with expensive replacement parts for a helicopter that is a joy to fly, then the Raw 420 is the heli for you.

R
Ron J.
Raw 420

SAB makes great products, easy to build and a joy to fly. It is hard to go wrong with SAB products.

R
R.J.
Awesome little bird

What can you say about SAB products... Quality!
Everything fits perfectly together, the instructions are easy to follow and I like the look too!!!

V
Varley
Goblin 420

Excellent small helicopter, especially for a beginner such as myself. Everything went together perfectly. Excellent service from HeliDirect - thanks.

S
Scott M.
SAn RAW 420

Assembly is great. Very straightforward. Only issue I had was there was one hole in the carbon fiber frame that wasn’t drilled. Great kit

F
Frank L.
Sab 420

It’s pretty amazing! It should have came with jtx connector’s thats my only complaint!

L
Lenny V.
raw 420

Great heli a beautiful beast in the air and the manual makes the building and setup of it a breeze.

L
Leonardo F.
Goblin raw 420

Awesome quality and light speed shipping from helidirect

J
Johnny
First Sab

I have a friend that is an awesome heli pilot, and he flies a Sab 700. The machine always amazed me; the precision and engineering are not just functional - it is a work of art. I didn't think I would be able to afford a Sab for years, until I saw the Raw 580. I have just begun building it, and it is amazing. The fit and finish is all great quality. I've been building Blade and Align kits, and they are good, but I think my next build will also be a Sab. Great product at a great price. Thanks HeliDirect!

R
Robert D.
Love it

Sab never disappoint me
Absolutely recommend for every heli enthusiast
Thank you Helidirect
