Axisflying 5" Brushless Top Quality FPV Motor AF227-1960KV For Juicy / Sbang / Bando Freestyle

- AF series motor are axisflying highest quality line with Premium performance, the highest standard.

      - AF227 motors released with 2 KVs, 2010 and 1960 for 6s, 2010kv is main for FPV racing, 1960KV is the most popular KV for freestyle with silky smooth and torquey low throttle with an sabng curve.

*Bearing Shield Technology

- An IP53 rating dustproof and waterproof bearing placement design.

- BST protects from environmental elements and prolongs the smoothness and lifespan of the bearng .

- Increased thrust effciency and say goodbye to crush motor bearings

*Specs

- 1960KV is for Sbang style freestyle @6S

- 2010KV is for racing @6S

- Configuration: 12N14P / N52H arc magnet

- Motor stator size: 2207

- Motor mounting hole size: 4*M3 (Φ16mm)

- Motor cables: AWG 20#, 150MM

- Motor dimensions (Dia *Len): Φ27*33MM  / M5 shaft

- Motor weight (excluding 150MM cables) : 30g

- The motor is very powerful that can get over 1.9KG and most current is about 45A

*Package

- 1* AF227 motor

- 4* M3*8 screws for motor

- 1* M3*4 screw for lock shaft

- 1* M5 Flanged Nylon Insert lock

- 1* O-ring

- 2* Washers
