Align T-Rex 550DFC/550L/550X 3-Bladed Main Rotor Head Set

Align
|
H55H004XXT
You will earn 218.99 points for buying this product
Price Match Guarantee
$197.09 $218.99( / )
Product: Product: Product: Package: Instruction: Specification: ●Suitable for T-REX 550/600●For T-REX 550E and T-REX 600, must use with 600DFC Main Shaft Set(H60243A).●The new 550E Three-Blade Rotor Head is specially made from 3-D rotation surface process, as well as aerospace grade aluminum alloy, strongly enhance structural toughness and precision. Also painted...

Product:
Product:
Product:
Package:
Instruction:Specification:
●Suitable for T-REX 550/600
●For T-REX 550E and T-REX 600, must use with 600DFC Main Shaft Set(H60243A).
●The new 550E Three-Blade Rotor Head is specially made from 3-D rotation surface process, as well as aerospace grade aluminum alloy, strongly enhance structural toughness and precision. Also painted with high texture and bright red satin plating color highlight the extraordinary craftsmanship and beauty all in one. The new three-blade head provide superior flight stability with low CG design allow to reduce flying resistance but bring more rigidity and fast response on the other hand. Pilots can easily control between active and static condition, and enjoy the pleasure from the flight.

Optional Equipment:
●550E Three Tail Blade Set(H55T005XXW)
●520 Carbon Fiber Blades / 3(HD520D)
●90 Carbon Fiber Tail Blades / 3(HQ0900D)

●Three-Blade Rotor Housing x 1
●Metal Main Rotor Holder x 3
●Three-Blade Shaft Set x 3
●Head Damper (Φ8xΦ12.9x6.5mm) x 3
●Elevator ball link (Φ5xΦ6x19mm) x 6
●550E Three-Blade Shaft screw x 3
●Linkage rod A x 3
●Spacer (Φ8xΦ11x1.3mm) x 3
●Spindle bearing spacer (Φ10xΦ13.8x0.4mm) x 6
●Thrust Bearing F8-14M (Φ8xΦ14x4.5mm) x 3
●MR148ZZ Bearing (Φ8xΦ14x4mm) x 6
●Washer (Φ5xΦ12x1mm) x 3
●Socket Collar Screw (M3x6mm) x 6
●Socket Screw (M3x10mm) x 2
●Socket Button Head Screw (M2.5x8mm) x 2
●Socket Collar Screw (M3x19mm) x 2
●Socket Collar Screw (M4x25mm) x 3
●Socket Screw (M5x10mm) x 3
●M3 Nut x 2
●M4 Nut x 3
●Main Blade Grip Arm x 3
●Φ5 Linkage Ball B (M3x4) x 3
●Elevator Arm Set x 2
●Linkage Rod Set x 1
●Washer (Φ3xΦ4.8x0.3mm) x 2
●Linkage rod holder x 6
●550E Three-Blade Rotor Main Shaft x 1
●Main shaft spacer 0.3mm x 1
●Main shaft spacer 0.5mm x 1
●CCPM Metal Swashplate x 1
●Linkage Ball B (M3x4) x 5
●Φ5 Linkage ball D (M3x3.5) x 1
●Φ5 Long linkage ball (M3x4) x 1
Type:

Helicopter Part

Vendor:

Align

SKU:

H55H004XXT

Weight:

2.5 lb


Product Spare Parts


Electronics

Customer Reviews

Based on 10 reviews
90%
(9)
0%
(0)
10%
(1)
0%
(0)
0%
(0)
R
Raymond D.
Aline tri blade rotor head

Not installed yet but a nice product

P
Paul K.
Three blade rotor is nice

The machine work and fit on this rotor head is really beautiful and it works great. You may however have to shorten the linkages from the servo arms to the swash plate and lengthen the linkages from the swashplate to the blade grips in order to get enough clearance from the red arms to the top rotor retaining bolt. Helicopter flies incredibly stable but also really aerobatic.

C
Customer
linkage rods attach to the servo horns should be provided too!

Should provide 3 linkage rods to attach to the servo horns

笹尾 喜.
It is a product with high cost performance.

Easy to assemble.
I wish the main blade grip arm was silver instead of red.
I think silver is the best for scale helicopters.

M
Michael R.
Great for scale projects

Excellent head for scale aircraft. Used them successfully in several scale models.

I
Ivan H.
3 blade head

Excellent product

M
Michael Y.
3 blade head

easy to assemble. looks great .very easy to track blades

M
Mayor50
Align 3 blade setup

I got this for my 550 X along with 3 blade tail set up Im only flying sport right now this set up was smooth as silk and very responsive just set the blade linkages, did not touch the swash plate or set up and it flew perfect. Nice product and Heli direct as always great service and support.

J
Jason R.(.
Three bladed 550X

This set-up is remarkable. Heli is incredibly responsive and agility is a 10/10!!!

T
Thomas D.

Good product and fast shipping . Not Direct fit for the 600 . You have to do some mods. Main shaft don't work with 600 you need to use stock shaft and head has 2 holes . You need to use bottom hole on head on 600 or it will bind. you will also have to extend linkages to get 0 on your setup. But its a direct fit for the new 550L.
