Scorpion Tribunus III 14-150A ESC SBEC

The Tribunus III 14-150A ESC marks a new era of electronic speed controllers from Scorpion Power Systems. Utilizing all Western Components and manufactured in Taiwan, this next generation ESC delivers exceptional capabilities with significant improvements over our previous models. Combining our proprietary and unique design, with our proprietary motor control algorithm, we provided one of the most reliable, safe, capable, and intelligent ESC's on the market for your hobby aircraft or industrial UAV.

Key Features:

• New PCB and Case Design: Engineered to reduce temperatures for efficient operation.
• Enclosed Capacitors: Featuring higher capacitance for improved performance.
• Ultra Strong BEC: Adjustable output voltage from 5V to 12V
• Integrated Mounting Tabs: Simplifying installation.
• Luxurious Two-Tone Anodizing: Enhancing aesthetics without compromising functionality.
• Next Gen MOSFET Technology: Unlocking greater potential and reliability.

• Also this ESC will ship with Firmware 16: The Telemetry Update
  The ESC will ship with FW 16, introducing two new telemetry protocols for FR.Sky and JR DMSS — bringing our total to seven communication protocols compatible with countless setups.
• Additionally, FW 16 features a super smooth spool-up function, perfect for both airplanes and helicopters.


Specifications:

• Max Continuous Current: 150 Amps
• Peak Current: 200 Amps
• Operating Voltage Range: 12 - 61.0 Volts
• BEC Output Voltage: 5.1V to 12.1V adjustable
• Max Continuous BEC Output: 15 Amps @ 8.1V
• Peak BEC Output: 30 Amps/1s @ 8.1V
• On Resistance: 0.6mOhms * 2
• ESC Body Size: 40.0 x 77.1 x 29.9 mm (1.58 x 3.03 x 1.18 in)
• Mounting Tab Dimensions: 16.0 (Battery Side) / 28.0 (Phase Side) x 86.0 mm (0.63 / 1.10 x 3.38 in) / M3 Bolt
• Weight (With Wires): 218g (7.69oz)
• Weight (Without Wires): 148g (5.22oz)
• Drive Frequency: 8kHz - 32kHz
