Stator Diamrter 40mm
Stator Thickness 25mm
No.of Stator Arms 12
Magent Poles 10
Motor Wind 3.5T/△
Motor Wire 13×0.35mm
Motor KV 1080
No-Load current(Io/10v) 3.5A
Motor Resistance(RM) 0.0076 Ohms
Max Continuous Current 95A
Max Continuous Power 2350W
Weight 308g
Outside Diameter 49mm
Shaft Diameter 5mm
Body Length 50mm
Overall Shaft Length 71.5mm
Max Lipo Cell 6s
Peak Current 125A/5s
Peak Continuous Power 2850W
| Vendor: | XLPower Heli |
| SKU: | XL52M03 |
| Barcode: | XL52M03 |
| Availability: | Out Of Stock |
| Product Type: | Electronics |
| Weight: | 2.0 lb |
This was or is the motor for the Nimbus 550 machine and since the price was so low I decided to try it out. I just got to solder the ends on it that came with it and try it out. I paid only $68 for it and it also comes with the tron Genesis Heli for free right now. It would also I guess work with the Tron Orion Heli also since they are basically the same except the lower frames and colors and canopy shape from what I read.
Excellent motor for the cost. Nimbus 550 v2 works well.
Got it on sale and couldn’t be happier!
very good quality and it is has good torque
When I build my Nimbus 550, I used an old motor that was at the minimum kv. When I installed the new motor the head speed was even lower. While at the field someone suggested recalibrating the Hobbywing ESC governor to the new motor. WOW what a difference.
Good motor for the money.
