HobbyWing QUICRUN Fusion Mini16 (2in1 FOC system)
){kind=link}
Manual
The QuicRun Fusion Mini16 FOC systemfeatures an integrated design of the ESC and motor, simplifying the car frame layout and wiring for enhanced convenience. Employing FOC (Field Oriented Control)driving mode for rock crawlers, it delivers strong low-speed torque, improving upon standard brushless systems and often being preferred over brushed systems for its overall feel.
The system boasts high efficiency, generates less heat, and effectively extends run time while the motor operates more quietly and smoothly. With an IP65 protection grade, it’s capable of running in all conditions. It offers intelligent torque output and speed closed-loop control for precise handling and includes active drag brake force adjustment, providing superior holding power on inclines.
Equipped with a strong built-in switch mode BEC, the system offers a continuous current of up to 4A and supports switching between 6V and 7.4V, enabling it to drive high-torque and high-voltage servos. It also includes multiple protection functions: battery low voltage, overheat, throttle loss, and lock-up protection. For convenient ESC parameter settings, it supports LCD and LED program boxes
Smart Torque Output & Closed-loop
Speed Control for Easy Control
Up the hill
The Fusion mini16 system automatically increases the
torque output to overcome resistance and accelerate
up the hill.
Going down the hill
the ESC automatically reduces the torque output and
stabilizes the vehicle speed when going down the hill.
| Type: | |
|---|---|
| Vendor: | |
| SKU: |
30120403 |
| Weight: |
0.2 lb |
Product Spare Parts
Customer Reviews
I put this setup in my Arrma Grom and it has been a great time. Ripping around in dirt on 3s has been wonderful.
Low end control is nothing short of Amazing!! Truck Loads of Umph to launch you into orbit. Installed the HW mini16 into a UTB18 Capra and it's Great!!! The control with the FS-GT5 is simply out of this world. I can't say enough about how good it is... do yourself a favor and just buy it !!!
I have two and about to order a third one. I modified mine to fit in my Arktos 6x6 rigs and it’s the perfect upgrade for this truck. It’s quiet, powerful, and fast in second gear. And it’s great because there’s not too much space to work with inside the Arktos. And it is programmable with the new HW G3 Pro programming box.
I purchased this specially for the UTB18, and I was quite happy to see that everything fit without any major modifications. It is super quiet compared to the Furitek Python UTB18 combo. The only reason I can’t give it 5 stars is because 1) it doesn’t come with a programming card, and 2) even with said card, it’s a pain to configure compared to the Furitek. Most of the tweaks I wanted to do could be done by my transmitter, so it wasn’t a show stopper for me.
This Fusion motor/esc is top notch. Saves space and no Soldering.
