Tron 7.0 Dnamic Helicopter Kit (w/o Blades) - Orange

Tron 7.0 Dnamic. Helicopter Kit, without blades and electronics.

The new Tron 7.0 DNAMIC ultralight 700 class Helicopter delivers stunning flight performance starting from 6S up to 12S lipo battery configurations.
The DNAMIC was already considered in the development of the Tron 5.8, but with appropriate changes to meet the need for a 700 size helicopter flying with a lower head speed and weight.
An updated and larger rotor head, a new tail transmission and various other changes have found their way into the DNAMIC to deliver you an absolutely precise and agile helicopter.
Excellent stability with bulletproof tail authority.
Last but not least, the take-off weight is once again, second to none!

 Take off weight example:

• 3* full size low profile servos.
• 1*full size tail servo.
• Scorpion 4225-830kv motor.
• Scorpion 130HV ESC.
• 700mm main and 105mm tail blade.
• 6S-5500mah 80C battery.
• NEO FBL system.
• Take off weight : 3700 grams / 8.15 pounds.

Features and specifications:

• CNC Maingear 137 T /MOD 09
• Motor pinion 13T /14T /15T /16T /17T
• Tail maindrive pulley 101T
• Tail back side pulley options available /20T /19T /18T Tail gear ratio from 4.8 up to 5.8 possible ( 5.05 =20T stock )
• Mechanic weight with canopy and batterie tray =1650 grams.
• Mini or full-size cyclic servo option. (Adapters included in kit)
• Motor mounting features a bearing block supported pinion, reducing overall wear on the power system and drive train.
• Compatible with a wide range of motor sizes. 4020, 4025 or 4225 series. ( 6mm shaft diameter with min 15mm lenght required )
• Weight RTF = ( 3650 grams with 6s-5500mah lipo 3* FULL LOW PROFILE servo1* FULL TAIL servo, ESC- Scorpion130HV ,Scor pion 4225 size motor.
• Supersonic canopy mounts included in kit. ( backside )
• Semi Fusion edition design included in kit. ( frame and tail fin stickers )
• Heavy duty one way bearing and hub design.
• Innovative FBL tray. ( Adjustable dampening hardness)
• Octa boom design with oval side shapes,
• Capable to use a wide range of lipo batteries. ( 6S-5000mA to 5500mAh 7S 4500-5000mAh /8S-4500mAh recommended or 12S- 3300mAh stickpack )
• High visibility canopy for perfect orientation in flight. 2 option available.
• Headspeed range from 1100rpm up to maximum 2000rpm!
• Maximum main blade lenght 705mm / tail 105mm
